SPECIFICATIONS:

10,000# capacity
Has Pick and Place capability
Hydraulically powered conveyor rolls
3.5" dia. x 76" face rolls on 6.5" centers
1 3/8" Round shafts
81" table length
36.75" conveyor pass height when lowered
61.75" from floor to top of horn when raised
5" wide x 8" high x 19" long horn, hydraulic extention
2 hydraulic cylinders for lift off arm of Turnstile
2 hydraulic cylinders for tilt
Forward and reverse of unit to clear next coil during removal is
actuated by a
 hydraulic cylinder. Unit travels via Cam Rollers on 4.25" high #60
Rail.
Cams are 2.5" above the base of the unit.
All height dimensions are minimum dimensions from the floor utilizing
#60 Rail floor mounted.
