SPECIFICATIONS:

MFG: COE Press Equipment
Model: CPR.DE.PO 10030
S/N: 6397.4

10,000lbs Capacity
24" Max. Width of Coil
18-22" ID Range
72" OD
Hydraulic Expansion
Floor to the Center Line of Mandrel: 66"
Feed Up Drive
Brake
Powered Rotation between Mandrel "A" & Mandrel "B"
Powered locking Pin

Attached Monarch Brand Hydraulic Power Unit:
Baldor Motor
3 HP
208/230/460 V.
8.5/8.2/4.1 Amp.
60hz, 3ph.
1725 RPM

Coil Cart
10,000 lbs Capacity
Bottom of "V" to floor: 32"
Dwck width: 32"
Measurement across Coil Cart: 44.5"
Hydraulic Lift & Travel

90 x 122 x 92"H approx. ship dimensions
